Required PTO HP | 20 - 50HP | Flywheel Thickness | 0.75in |
Chipping Diameter | 6in | Flywheel Housing System | Easy To Open Clamshell |
In-feed Chute Opening | 25.6 x 25.2 in | Flywheel Housing Thickness | 0.3in |
In-feed Opening | 6 x 8in | Flywheel Shaft | 2in |
In-feed Chute | Quick folding for transport/storage | Hydraulic Oil | 5.3 gal of ISO 32 or ISO 46 (warmer climates) |
In-feed System | Self Contained Hydraulic System | Hydraulic Pump | Yes - Belt Driven |
In-feed Drive | Forward/Neutral/Reverse with Variable Speed: (0-75 ft/min) | Discharge Chute | 360 Degree Swivel |
In-feed Roller Size | 8in Chisel Tooth | PTO Shaft | Shear Pin Protected PTO Shaft Included |
In-feed Roller Pressure | Adjustable via Spring Tension | PTO Shaft Length | T4/31.1-38.3 in |
Quick Hitch Compatible | Cat 1 Quick Hitch | Number of Blades | 4 Reversible Blades |
Spline End | 1 3/8"Z6 | Finish | Powder Coat Paint |
3 Point Hitch | CAT1 | Warranty | 1 Year |
Flywheel Speed | 540 RPM | Dimensions (L x W x H) | 45x33x45 in |
Flywheel Drive System | Direct Drive | Net Weight | 695 lbs |
Flywheel Diameter | 24in | Gross Weight | 800 lbs |
WARNING: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soot, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
