Power Required | 25-45HP | Main Gearbox | ASAE 1- 3/8″ – 6 spline shaft, proven cast iron, oil bath gearbox; ratio is 1.69:1 |
Working Width | 53 in | Drive Gear Ratio | 1:52:1 |
Overall Width | 60 in | Gearbox Oil Type | SAE 85W-90 |
Working Depth | 1in,2.1in,3.1in,5.1in | Deck Thickness | 0.16 in |
Number Of Flanges | 6 | Side Plate Thickness | 0.31 in |
Number Of Blades | 30 | PTO Shaft RPM | 540 RPM |
Blade Type | c type | PTO Shaft | T4-31in 8 Bolt non-removable slip clutch |
Blade Material | 60SI2MN | Spline End | 1.375in X z6 |
Rotor Bearing | NSK bearing | 3-Point Hitch | CAT 1 |
Rotor Diameter | 3 in | Deflector | Rear Hinged |
Rotor Swing Diameter | 19.5 in | Finish | Powder Coating |
Rotor Thickness | 0.3 in | Dimensions (Lx W x H) | 60 X 32 X 31 in |
Rotor Shaft Speed | 215 RPM | Warranty | 1 year |
Rotor Rotation | Forward | Net Weight | 643 lbs |
Drive Type | Gear Drive | Gross Weight | 760 lbs |
