Model | UC32 |
Voltage | 208–240V AC, 60Hz, 3-Phase (3P + Ground) |
Recommended Wire | AWG 10 Cu |
Ultrasonic power | 1.1KW / 1.5HP |
Heating power | 6.6KW / 9HP |
Temperature Control Range | Ambient to 149°F (65°C) |
Ultrasonic Frequency | 28kHz |
Transducer QTY | 20 Pcs (industrial-grade) |
Machine Size（L×W×H） | 43.3×26.3×29.1 in |
Tank Size（L×W×H） | 29.5×15.8×15.8 in |
Big Basket Size（L×W×H） | 25.9×14.4×12.6 in |
Weight Capacity ( Big Basket ) | 176 lbs( 80 kg) |
Small Basket Size（L×W×H） | 14.4×8.1×8.6 in |
Weight Capacity ( Small Basket ) | 22 lbs ( 10kg ) |
Tank Volume | 32GAL / 120 L |
Tank material & Thickness | SUS304 / 1.5mm |
Outer Panel Material & Thickness | SUS201 / 1.0mm |
Packing Size（L×W×H） | 49×31×35 in |
N.W./ G.W | 286 / 408LBS |
