Engine | DUCAR DH275 | Lubricant Tank Size | 2.6 gal |
Engine Type | Single Cylinder, 4 Stroke, Air-Cooled, OHV | Track Load-Bearing | 2 ton |
Engine Displacement | 274 cc | Track Width | 2 ft 2 in |
Horsepower | 8.1 HP | Track Length | 13 ft |
Start | Recoil | Track Extension Length | 6.4 ft |
Log Diameter | 22 in | Leveling Feet | 12 |
Max Live Edge Width | 18 in | Log Rests | 2 Long and 2 Short Rests |
Standard Cutting Length | 10.4 ft | Log Clamps | 2 x Quick Lock |
Max Board Thickness | 6 in | Track Bunks | 1.6 x 3.9 in |
Blade Engagement System | Centrifugal Clutch | 4 Post Head Design | Yes |
Cast Iron Bandwheel Diameter | 16.5 in | Finish | Powder Coat Paint Galvanized Steel |
Blade Wheel Engagement | Belt Drive | Sawmill Warranty | 2 Years |
Blade Guide | By Block | Engine Warranty | 1 Year |
Blade Tension | By Adjustable Lever | Package Method | Wood |
Blade Size | 127 x 1.3 in | Packing Size | 87 x 19 x 32 in |
Blade Pitch | 7/8 in | Weight (N.W./G.W.) | 509/600 lbs |
Blade Lubrication | Water Lube - Manual Valve |
|
|
