Model | GH4235 |
SKU | 500423 |
Max. Cutting Capacity | ● Ø13-3/4" (350 mm) ■ 13-3/4"×13-3/4" |
Cutting Speed | 187 / 284 ft/min |
Feed Speed | Hydraulic Variable Speed |
Blade Size | 162.01"×1.34"×0.043" (4115×34×1.1 mm) |
Workpiece Clamping | Hydraulic |
Blade Tensioning | Mechanical |
Main Motor Power | 2.2 / 2.8 kW |
Hydraulic Motor | 0.55 kW |
Coolant Pump Motor | 0.04 kW (40W) |
Drive | Worm bar |
Net Weight | 1940.06 lbs (880 kg) |
Gross Weight | 2094.39 lbs (950 kg) |
