Power Required | 80-120 Hp |
Working Width | 100 in |
Overall Width | 106 in |
Blade Ground Clearance (Four Gears) | 0.2-0.9-1.7-2.4 in |
Max. Cutting Diameter | Depends On The Type Of Grass |
Offset Distance from The Center (Maximum) | 130 in |
Tilt-Up Angle | 90° |
Tilt-Down Angle | 55° |
Number Of Blades | 24 |
Number of Belts | 4 |
Blade Type | Hammer |
Blade Weight | 2.6 lbs |
Blade Material | Cast Steel |
Belt Adjustment | Bolt Tightening |
Rotor Diameter | 5.5 in |
Rotor Thickness | 0.5 in |
Rear Roller Diameter | 6 in |
Rear Roller Thickness | 0.25 in |
PTO Shaft Speed | 540 rpm |
Deck Thickness | 2 in |
Side Plate Thickness | 0.25 in |
Gearbox (RPM 540) | 65 HP CMR Italian gearbox |
Driveline Shaft Length | 06B-73SBWith Shear Bolt; 73in-126in |
Spline End | 1.375in Z6 |
3-Point Hitch | CAT 2 |
Gearbox 0il Type | 85W-90 |
Finish | Powder Coating |
Warranty | 1 Year |
Shipping Box | 121 X 43 X 37in |
Weight (N.W./G.W.) | 2100 /2344 lbs |
