Specification | 1022VD |
Motor | 1.5 HP, 110V, single-phase, 10A |
Swing Over Bed | 9-7/8" (250 mm) |
Swing Over Cross Slide | 5-1/2" (140 mm) |
Swing Over Saddle | 5" (127 mm) |
Distance Between Centers | 21-5/8" (550 mm) |
Bed Width | 5-3/8" (135mm) |
Spindle Bore | 1-1/2" (38 mm) |
Spindle Mount | Intrinsic back plate |
Spindle Type | One-piece Spindle |
Spindle Taper | MT#5 |
Tailstock Taper | MT#2 |
Tailstock Quill Travel | 3" (75 mm) |
Cross Slide Travel | 5" (127 mm) |
Compound Slide Travel | 3" (75 mm) |
Carriage Travel | 19-5/8"(500mm) |
Spindle Speeds | 0–2000 RPM |
Number of Speed Ranges | Variable |
Longitudinal Feeds | 0.0025 – 0.014 in./rev. |
Transverse Feed Rate | 0.0014 – 0.004 in./rev. |
Leadscrew Size & Pitch | 20mm(8TPI) |
Threading Capacity - Inch | 8–80 TPI(37KINDS) |
Threading Capacity - Metric | 0.35 – 3.0 mm(21kinds) |
Maximum Tool Bit Size | 15/32''(12mm) |
Thread Dial Indicator | YES |
Coolant System | OPTIONAL |
Overall Dimensions | 44.0" × 25.0" × 19.0" (1220 × 635 × 480 mm) |
Approximate Shipping Weight | 308/352 lbs (140/160 kg) |
